C723 Soft Serve Freezer Twin Twist Features
Offer all the popular soft serve variations from low or nonfat ice creams to custards, yogurt and sorbet. Serve two separate soft serve flavors, or an equal combination of both in a twist.
Two, 2.8 quart (2.7 liter).
Two, 14 quart (13.2 liter). Separate hopper refrigeration (SHR) maintains mix below 41ºF (5ºC) during Auto and Standby modes.
Digital readout displays hours since last brush cleaning to assure product safety. Mix Low light alerts operator to add mix. Audible alarm may be enabled to sound when mix is low. When the Mix Out light flashes, the unit shuts down automatically to prevent damage.
Touch Screen Controls
Microprocessor touch controls are embedded in durable tempered glass panel. Multiple languages are selectable. Viscosity is continually measured to dispense consistent quality soft serve desserts. Temperatures in the hoppers or freezing cylinders may be displayed at any point of operation, in either Fahrenheit or Celsius. Draw counter allows operator to view number of servings dispensed.
During long no-use periods, the standby feature maintains safe product temperatures in the mix hopper and freezing cylinder.
Door Interlock System
Protects the operator from injury as the beater will not operate without the dispensing door in place.
A specially designed thermo-plastic door allows quick ejection of product with a simple movement of the draw handle. Self closing draw handles are standard.
Taylor C723 Specifications
One dedicated electrical connection is required. See the Electrical chart for the proper electrical requirements. Manufactured to be permanently connected. Consult your local Taylor distributor for cord & receptacle specifications as local codes allow.
Two, 1.0 HP.
One, 9,500 BTU/hr. R404A.
Separate Hopper Refrigeration (SHR), One, 400 BTU/hr. R134a. (BTUs may vary depending on compressor used.)
Minimum 6” (152 mm) on both sides. It is recommended to place the rear of the unit against a wall, or allow 6” clearance (152 mm) at the rear. Optional air discharge chute directs heated air exhaust upwards; minimum clearance above top air discharge chute is 12” (305 mm). No clearance required on right side if air discharge chute is used.
Water inlet and drain connections out rear panel 3/8” FPT.
Taylor C723 Options
- Standard Cart with casters and a door (shown) Net Weight: 74 lbs. (33.6 kg) Crated Weight: 95 lbs. (43.1 kg)
- ADA Cart with casters – recommended for self service to meet ADA compliant dispensing height – no door (see C723 ADA spec. sheet) Net Weight: 74 lbs. (33.6 kg) Crated Weight: 87 lbs. (39.5 kg)
- Drain Adaptor (for ease of rinsing & cleaning)
- Draw handles to comply with ADA force requirement
- Draw Valve Lock Kit
- Hopper Locks
- Hopper Agitators
- Legs – [increase height of unit by 4-1/4” (108 mm)]
- Decals – Twist or Flavor Burst Cone
- Top Air Discharge
